DVB-C
DVB-cable
digital TV receiver
digital cable receiver
digital video broadcast
solution: Hisilicom ; ( Chipset optional : Montage )
Panel size optional: 168mm*95mm*35mm
148mm*95mm*35mm
115mm*95mm*25mm
128mm*90mm*30mm
220mm*150mm*40mm
240mm*200mm*38mm
basic version on FTA model without CAS and Smart Card, to intergrate CAS slot will add extra cost;
And The CAS agreement fee will be paid seperately and subject to the CAS company.
About HDMI cable / AV cable , optional
| Hardware Specification | ||
| Chip & Board | Main Chip | HM1521M |
| SDRAM | DDRi 16M*16bit*1pc | |
| TUNER Number | TC2800 | |
| TUNER TYPE | Silicon | |
| Front Panel | LED | Power Indicator (LED):(Standby, Lock) / show channel number and etc. |
| Key | 7PCS(Power, Up, Down, Left, Right, Confirm& Menu) | |
| Smart Card Slot | ISO 7816 | |
| Rear Panel | Tuner RF input connector | IEC Female x1 |
| Tuner RF Loop through connector | IEC Male x1 | |
| CVBS | x1 | |
| YPbPr | x1 | |
| 4-pin Software Update Port | x1 | |
| Basic User Interface Features (common features) | ||
| OSD | Supported Language | English, Chinese |
| Subtitle | English, Chinese | |
| TV System | Display Mode | 720i, 576p, 576i, 480p, 480i |
| Aspect Mode | 4:3,16:9 | |
| System Spec | ||
| Video | Decoder | MPEG-1/2 Video Decoder |
| Display Resolution | 2. 720 * 576(PAL) 720 * 480(NTSC) | |
| Standard | ISO/ IEC 13818-2 MPEG- 2 MP@ML | |
| Audio | Standard | ISO/IEC -11172-3 |
| Decoder | MPEG-1 Layer I/II | |
| Mode | Dual (main/sub), Stereo | |
| Frequency | 44.1,48KHz | |
| Response | 20HZ~20KHZ +/-2Db | |
| SNR | min.76dB | |
| Input& Output | Input impedance | 75Ω |
| Signals level | -25dBmV~+25dBmV(64QAM) | |
| Input Frequency | 47MHz-862MHz | |
| Decoding | 16/32 /64 /128 /256 QAM | |
| Support scope | 3.6-6.952MS/s | |
| Power Supply | Power input voltage | AC90~250V 50~60Hz |
| Power Consumption | 10W max | |
| Operation Temperature | 0°C~40°C | |
| Product dimension | ||
| Qty per unit packing | 1 pc | |
| Unit packing: (LxWxH) | 230*210*45mm | |
| Unit packing (G.W.) | approx. 0.8kg | |
| Qty per export carton | 20pcs | |
| Export carton (LxWxH) | 53.0*45.5*25.5 cm | |
| Export carton (G.W.) | 15.5kgs | |
| Units per 20" / 40" / 40"HQ | 9180 /16390/ 21310pcs | |
| Accessories : | Remote Control,RCA cable, User Manual, Gift Box | |
