Cjtouch 17-inch waterproof touch LCD display 17\\" IP68 touch screen display

CJTOUCH 17inch waterproof Touch Lcd Display Monitor 17" ip68 touch screen monitor Advantage of our IR touch monitor:· Industrial Desgin With Excellent Durablity· IR Technology Multi Touch 2-10 Touch Points· IP65 Touch Screen Surface Water-Proof Sealled· 3MM Enhanced Glass With Vandal Pr

Featured Products

CJTOUCH 17inch waterproof Touch Lcd Display Monitor 17" ip68 touch screen monitor


Advantage of our IR touch monitor:

· Industrial Desgin With Excellent Durablity

· IR Technology Multi Touch 2-10 Touch Points

· IP65 Touch Screen Surface Water-Proof Sealled

· 3MM Enhanced Glass With Vandal Proof Resistance

· High Light Transmission Clear Glass

· Easy to Use:Plug and Works on Windows/Linux/(Android)

· Perfect Solutions For Use In Public

· VESA Mounting and Rear Mounting

· OEM/ODM& Customized Option: Brightness/Computer Integrated Inside/Etc

· Factory Competitive Price & Fast Delivery


Drawing :

Cjtouch 17inch Waterproof Touch LCD Display Monitor 17

Details Pictures:


Cjtouch 17inch Waterproof Touch LCD Display Monitor 17

Specifications:


General
ModelCOT170E-IWF02
SeriesWaterproof and Compact
Monitor DimensionsWidth: 368mm  Height: 306mm  Depth: 49.5mm
LCD Type17"SXGA Color TFT-LCD
Video InputVGA and DVI
OSD controlsAllow on-screen adjustments of Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
Power SupplyType: External brick
Input (line) voltage: 100-240 VAC, 50-60 Hz
Output voltage/current: 12 volts at 4 amps max
Mount Interface1)VESA 75mm and 100mm
2)Mount bracket, horizontal or vertical
LCD Specification
Active Area(mm)337.920(H)×270.336(V)
Resolution1280×1024@75Hz
Dot Pitch(mm)0.264×0.264
Nominal Input Voltage VDD+5.0V(Typ)
Viewing angle (v/h)85°/80°
Contrast1000:1
Luminance(cd/m2)250
Response Time(Rising/Falling)5s/5s
Support Color16.7M colors
Backlight MTBF(hr)30000
Touchscreen Specification
TypeCjtouch Infrared IR touch screen Dual touch
Resolution4096*4096
Light Transmission92%
Touch Life Cycle50 millions
Touch Response time16ms
Touch System InterfaceUSB interface
Power consumption+5V@80mA
External AC Power Adapter
OutputDC 12V /4A
Input100-240 VAC, 50-60 Hz
MTBF50000 hr at 25°C
Environment
Operating Temp.0~50°C
Storage Temp.-20~60°C
Operating RH:20%~80%
Storage RH:10%~90%

Package:

Cjtouch 17inch Waterproof Touch LCD Display Monitor 17



Certificates :


Cjtouch 17inch Waterproof Touch LCD Display Monitor 17

Application  :

Cjtouch 17inch Waterproof Touch LCD Display Monitor 17

Who we are ?


Dongguan CJTouch Electronic Co., Ltd. is a leading provider of Touchscreen, Touch monitor and All-in-one computers. With advanced, cost-effective touch solutions, CJTouch believes in engaging with customers while providing customized services.
Experience:
Established in 2006 and headquartered in Dongguan, China, CJTouch has proven to be reliable and trustworthy partners to help seamlessly integrate our products into your total solution.
 Over 10 years of combined experience in researching and developing touch-enabled screens and monitors.
 Two factories with over 200 skilled and qualified employees, including R & D engineers, technical experts and sales representatives.
What We Offer:
Through our consistent and high quality performance, CJTouch has got ISO 9001 certified and has earned CE, UL, FCC, RoHS and other international certifications.
 Single & Multi-touch screens (custom sizes available)
 Single & Multi-touch monitors (custom sizes and functions available)
 All-in-one computers
 ODM/OEM services
Technology:
CJTouch has always relied on continuous innovation to stay ahead in touch technology. We are committed to delivering the most cutting-edge solutions in the industry.
 Surface Acoustic Wave (SAW) touch technology
 Infrared touch technology
 Projected Infrared Touch technology
Applications:
We offer an extensive array of services with products being widely used in industries such as finance, gaming, retail, kiosk, health care, education, etc.
Cjtouch 17inch Waterproof Touch LCD Display Monitor 17
Our office :

Cjtouch 17inch Waterproof Touch LCD Display Monitor 17


Other products what we can offer :

Cjtouch 17inch Waterproof Touch LCD Display Monitor 17

Contact :

Cjtouch 17inch Waterproof Touch LCD Display Monitor 17
